MXR M288 Bass Octave Deluxe Guitar Effects Pedal
The M288 Bass Octave Deluxe is a dual-voice octave pedal that offers analog tone, true bypass, and a variety of tonal options. MXR's 18 volt Constant Headroom Technology provides high headroom and superior tracking.
Features:
- Effects Type: Octave
- Two independent analog octave voices
- Mid+ switch boosts selectable midrange
- Constant headroom Technology (CHT)
Specifications:
- Input Impedance: 1 MΩ
- Output Impedance: < 600 Ω
- Noise Floor: 85 dB
- Octave Frequency Bandpass: -3 dB, 8 Hz to 46 Hz
- Control Range: -∞ to +2.5 dB (Dry), -∞ to +1 dB (Girth), -∞ to +6 dB (Growl)
- MID+ Switch: +4 dB to +14 dB (Gain), 400 Hz or 850 Hz (Frequency)
- Bypass: True Hardwire
- Current Draw: 14 mA
- Power Supply: 9 Volts DC
More Images
MXR M288 Bass Octave Deluxe Guitar Effects Pedal
The M288 Bass Octave Deluxe is a dual-voice octave pedal that offers analog tone, true bypass, and a variety of tonal options. MXR's 18 volt Constant Headroom Technology provides high headroom and superior tracking.
Features:
- Effects Type: Octave
- Two independent analog octave voices
- Mid+ switch boosts selectable midrange
- Constant headroom Technology (CHT)
Specifications:
- Input Impedance: 1 MΩ
- Output Impedance: < 600 Ω
- Noise Floor: 85 dB
- Octave Frequency Bandpass: -3 dB, 8 Hz to 46 Hz
- Control Range: -∞ to +2.5 dB (Dry), -∞ to +1 dB (Girth), -∞ to +6 dB (Growl)
- MID+ Switch: +4 dB to +14 dB (Gain), 400 Hz or 850 Hz (Frequency)
- Bypass: True Hardwire
- Current Draw: 14 mA
- Power Supply: 9 Volts DC
